Hide Pro

Design: Piero Lissoni

Hide Pro represents the next phase of the Hide cabinet columns, containment modules with a single-sided structure that can be equipped inside to perform all the functions of the kitchen – storage, cooking, extraction, dishwasher, food preservation – and also house washing machine and dryer units. The opening mechanism of Hide Pro differs from the previous model as there is no track on the floor, which permits a seamless design and easy access to the cabinet. In addition, the push opening mechanism permits a handle-free solution as the door opens and closes by applying minimal pressure. The internal layout of Hide Pro differs from Hide in that it allows the possibility to insert base and wall units from the Boffi kitchen systems price list, thus offering greater design flexibility.

The fronts are full-height doors, simple or composite and foldable, which retract laterally when opened and thus disappear from view.

This constantly evolving system includes open elements and accessorized corner modules equipped inside with LED lighting or illuminated back panels.There is even space inside to house a service trolley.

Technical Details

FRONT FINISHES

The range of Boffi materials and their compatibility with individual products are constantly evolving: check with your dealer for the actual availability of the product in the desired finish.

LACQUERED METAL OF DE CASTELLI WOOD CLAY COMPOSITE LASERMAT GLASS STAINLESS STEEL

Water-based “soft touch” matt lacquer. Features: The following features make ECOLAK a top-quality finish: • Water-based “soft touch” paint, bi-component and undiluted (not contaminated by external agents), designed and produced exclusively for Boffi. • Colour range, exclusive for Boffi. • Excellent chemical and physical resistance – tested in laboratories. • Very low yellowing effect over time. • Coat of isolating paint Primer and double layers of polyester plastering, ideal for reducing small imperfections on surfaces and allowing a better coverage. • Base coat of polyester. • Coat of isolating paint Primer for corners and edges. • Two paint coats, cross-applied.

BASALT GREY

CHARCOAL

BLACK

ARTIC WHITE

WARM WHITE

MAGNOLIA

CLOUD

PEBBLE GREY

OAT

ÈCRU

MUD

The polyester lacquering is carried out by a process of applying paints on MDF panels, with several coats. The surfaces are sanded with different coarse-grained and fine-grained sandpapers. Then they are polished using brushes impregnated with abrasive wax. The result obtained is a very glossy surface (close to the mirror effect) that reaches 95 gloss. Polyester is a very resistant material, practically waterproof; its surface does not absorb, but is sensitive to scratches. The scratched surface can be re-smoothed and re- polished or even repaired adding material and then by sanding and smoothing it again. Three layers of paint coat each surface, it means 900 g/m2 (ca. 1 mm thick); nine layers of paint coat each edge (ca. 3 mm thick). It is sensitive to light if directly exposed for very long periods. It can slightly change the tone, becoming lighter especially on light tones (family of whites). In case of element additions in a second moment, these tone changes cannot be perfectly replicated and may not match exactly the original shade. This issue cannot be considered cause for a complaint.

FOREST GREY

WHITE

PEBBLE GREY

GREY RAL 7038

ELEGANT GREY

DEEP GREY

PETRA RED

Exclusive-appearance metal sheet obtained with special chemical and / or mechanical treatments. For generations the “mission” of De Castelli has been to enhance the natural metals such as iron, steel, brass and copper, making them unique thanks to dedicated and sophisticated mechanical or chemical treatments. The chromatic and aesthetic effects created are peculiar and highly distinctive. The metals of De Castelli are protected only by transparent paints, in full respect of the core of the metal used.

DeLabrè B E5 STAINLESS STEEL

STRIPPED DeLabrè 7022 F12 STAINLESS STEEL

ORBITAL DeLabrè G2 STAINLESS STEEL

DeOdd K4 STAINLESS STEEL

DeLabrè F2 BRASS

STRIPPED DeLabrè G7 BRASS

DeLabrè G5 COPPER

ORBITAL DeLabrè G4 COPPER

SATIN BRASS F1

DeOdd HAMMERED K3 STAINLESS STEEL

DeErosion Freehand 2.0 K6 BRASS

DeErosion Freehand 2.0 K5 COPPER

DeErosion points K2 BRASS

DeErosion points K1 COPPER

Metal-effect lacquer. Metals is a special finishing which reproduces the typical effect of brushed metallic surfaces, rendered through a very precise and technical sequence of production cycles. The characteristic metallic effect of the surface is given by the alternation of manual and mechanical processes, by the quality of the metal particles-enriched solvent-based paints and by the complex drying procedure. The various shades of colour (halos caused by the spread of the paint chromium particles) and the succession of multi-directional brushing of the surface make each piece a unique and exclusive one.

COPPER RAYÈ

BRASS RAYÈ

BRONZED BRASS RAYÈ

ANCIENT BRONZE RAYÈ

BRONZE RAYÈ

LEAD RAYÈ

ALUMINIUM

WHITE

ZINC+

VINTAGE BRASS

COPPER+

TITANIUM

LEAD

Composite material made of high-purity minerals, by using Full Digital technology. “Natural” matt finish. The decorative design is on the front surface only. Features: - Surface: smoother-feeling texture and total control over the design, leading to outstanding visual properties. - Hygienic and nontoxic: Because it has a non-porous surface, this prevents the build-up of bacteria or mould. - Resistant: It is highly resistant to stains, heat, frost, thermal shock, scratches and impacts, ultraviolet rays and has a low water absorption rate. - Ecological: -70% savings on water consumption and -90% reduction in atmospheric emissions during the production process. 50% made with recycled materials.

YORK

NEWLYN

WHITE

CAMEL

BLACK

BIHARA (Exclusive Boffi finish)

DEVON (Exclusive Boffi finish)

SURREY (Exclusive Boffi finish)

KANRAN (Exclusive Boffi finish)

CAMEL CROSS (Exclusive Boffi finish)

CAMEL POINTS (Exclusive Boffi finish)

BLACK CROSS (Exclusive Boffi finish)

BLACK POINTS (Exclusive Boffi finish)

Nanotechnological matt “soft touch” FENIX NTM® surface. FENIX NTM® The exterior decorative surface is obtained starting from thermosetting last generation resins that, thanks to the use of nanotechnology (NTM), make the surface extraordinary from a mechanical, aesthetic and functional point of view. FENIX NTM® UNICOLOR Obtained starting from thermosetting last generation resins that, thanks to the use of nanotechnology (NTM), make the surface extraordinary from a mechanical, aesthetic and functional point of view (colour-core).

BEIGE LUXOR

KOS WHITE

MALÈ WHITE

EFESO GREY

ANTRIM GREY

LONDON GREY

COMODORO GREEN

JAIPUR RED

BROMO GREY

BLUE FES

ORINOCO COCOA

INGO BLACK

BEIGE ARIZONA

Water-based textured matt lacquer. The following features make SILCOLAK a top-quality finish: • Water-based textured paint, bi-component and undiluted (not contaminated by external agents), designed and produced exclusively for Boffi. • Colour range, exclusive for Boffi. • Excellent chemical and physical resistance (tested in laboratories). • Very low yellowing effect over time. • Coat of isolating paint Primer and double layers of polyester plastering, ideal for reducing small imperfections on surfaces and allowing a better coverage. • Base coat of polyester. • Coat of isolating paint Primer for corners and edges. • Two paint coats, cross-applied.

RED RIBES

SIBERIA WHITE

PAROS WHITE

OYSTER-PEARL

LUTON GREY

GRAVEL GREY

HAY

ROPE

SLIT

SLATE GREY

ABYSS BLACK

JET BLACK

MYRTUS GREEN

Wood layers, with support made of strip wood. Boffi uses only wood from not primary forests, to guarantee an adequate restoration of the renewable raw materials. Doors and panels have vertical grain. The “old“ grey pinewood consists of pinewood solid boards recycled from renovation of old houses, barns and huts. The characteristic grey tone of this material is obtained by specific painting cycles, which give the typical “old” aspect to this wood. Possible cracks and deformations have to be considered characteristic part of the product. Since these pieces are very unique, they have the typical appeal of “imperfect things“ and they clearly display sign of times and bad weather; therefore they show deformations and wrinkles strength. Worktops obtained with old wooden boards offer a clear example of the wood vitality and instability. For this reasons each piece in solid wood has to be considered considered “unique“ and different from all the other ones.
